Dental micromotor Vortice
$360
Price excl. tax from
Connect
Need more information, prices, or a quote? Contact the manufacturer.
Free quotation
Contact manufacturer
SIMPLE&SMART
Italy
Characteristics
| application | dental |
| operation | air |
| Ergonomics | straight |
Description
Vortice is a pneumatic micromotor with speed and direction of rotation adjustable by means of the rotating ring.
General performance has been improved, and torque, now increased to 2.7 Ncm, remains extremely high across the entire speed range.
Micromotor is equipped with a non-return device for spray water. It can be employed with any straight or contra-angle handpiece with internal spray and connection compliant to ISO 3964 standard.
- Technical specifications
- Speed: 4000 – 22000 rpm
- Supply pressure: 2.4 – 3.0 bar
- Maximum consumption: 63 Nl/min
- Sterilization: In autoclave at 134° C, 2 bar
- Compliance: ISO 14457, ISO 3964
- Weight: 80 g
- Adjustable speed and direction via rotating ring
- High torque: 2.7 Ncm
- Non-return device for spray water
- Compatible with straight or contra-angle handpieces (internal spray, ISO 3964)
General performance has been improved, and torque, now increased to 2.7 Ncm, remains extremely high across the entire speed range.
Micromotor is equipped with a non-return device for spray water. It can be employed with any straight or contra-angle handpiece with internal spray and connection compliant to ISO 3964 standard.
- Technical specifications
- Speed: 4000 – 22000 rpm
- Supply pressure: 2.4 – 3.0 bar
- Maximum consumption: 63 Nl/min
- Sterilization: In autoclave at 134° C, 2 bar
- Compliance: ISO 14457, ISO 3964
- Weight: 80 g
- Adjustable speed and direction via rotating ring
- High torque: 2.7 Ncm
- Non-return device for spray water
- Compatible with straight or contra-angle handpieces (internal spray, ISO 3964)
